Cabie Stranding Machine

The JLK630/1+6+12+18+24 rigid framed stranding machine is engineered for high-efficiency stranding of copper and aluminum conductors with large cross-sections. Supporting up to 61 wires (10–400mm²) and single wire diameters from φ1.5–5mm, this machine is ideal for producing round, fan-shaped, tile-shaped, and irregular conductors. It also supports copper tape shielding and wrapping applications, making it a versatile solution for modern cable production needs.

The JLK630/6+12+18 rigid framed stranding machine is specifically designed for producing high-quality stranded conductors, including copper, aluminum, and ACSR. Supporting up to 37 wires with a cross-section range of 10–185mm², this machine ensures stable tension control, precision stranding, and compacting capabilities. It is ideal for manufacturing circular, fan-shaped, and tile-shaped conductor profiles in large-scale cable production environments.

The JLK630/6+12 rigid framed stranding machine is built for high-precision stranding of up to 19 wires with cross-sections from 10–70mm². Ideal for copper and aluminum conductors, it features split motor drive, automatic tension control, and wire preforming to ensure structural integrity of finished conductors. Designed for efficient and reliable production, it supports both round and sector-shaped wire compacting for diverse cable applications.

The JLK630/6+12+18+24+30 rigid framed stranding machine is engineered for heavy-duty cable manufacturing, supporting up to 91 wires with cross-sections ranging from 10–400mm². Designed for high-speed stranding of copper, aluminum, and ACSR conductors, it can produce round, sector, and tile-shaped cables. With a maximum stranding diameter of φ55mm and speed of 175r/min, this machine ensures reliable, efficient, and high-volume production for demanding cable applications.

The JLK630/24+24 Steel Wire Armor Rigid Framed Stranding Machine is designed for high-performance stranding of large-length, large-cross-section copper and aluminum core conductors. It produces round, sector-shaped, and tile-shaped irregular conductors while supporting copper tape shielding and wrapping. Featuring a robust dual-bearing frame structure, preforming technology, and automated tension control, this machine ensures precision, durability, and efficiency in cable manufacturing. Ideal for industrial applications requiring high-quality stranded conductors.

The JLK630/36+36 Steel Wire Armor Rigid Framed Stranding Machine is engineered for high-performance stranding of copper, aluminum, and ACSR conductors. With integrated automation, superior structural rigidity, and advanced electronic control systems, this machine ensures reliable, efficient, and precise stranding operations. Ideal for producing large cross-section and long-length conductors, it supports diverse shapes and optional shielding processes.

The JLK630/42+42 Steel Wire Armor Rigid Framed Stranding Machine is engineered for high-efficiency production of large-length, large-cross-section copper and aluminum core stranded cables. Featuring pneumatic tension control, ground axis linkage, and PLC automation, this machine ensures precision, stability, and high-speed performance. It supports round, fan-shaped, and tile-shaped irregular conductors, making it ideal for industrial cable manufacturing. With advanced electronic control and easy operation, it maximizes productivity while maintaining consistent quality.

The JLK 500/6+12+18+24+30 Rigid Framed Stranding Machine is engineered for the high-efficiency stranding of copper, aluminum, and ACSR conductors with large cross-sections and extended lengths. With its advanced automation, stable structure, and user-friendly interface, this machine delivers precision stranding for circular, fan-shaped, tile-shaped, and compacted conductors. It is an ideal choice for power cable and wire manufacturers aiming to enhance productivity and product quality.

The JLK500/6+12+18+24 Rigid Framed Stranding Machine is a high-performance solution for manufacturing copper, aluminum, and ACSR conductors with large cross-sections. Designed for versatile stranding applications, it produces round, fan-shaped, and tile-shaped irregular conductors, including copper tape shielding and wrapping. Featuring automated tension control, PLC operation, and shaft-less bobbin handling, this machine ensures precision, efficiency, and safety in industrial cable production.

The JLK500/6+12+18 Rigid Framed Stranding Machine is a high-precision stranding solution designed for efficient production of compact and round wire conductors. Built with a durable frame structure, dual-bearing support, and advanced automation, it ensures stable operation, easy bobbin handling, and excellent wire forming performance. Ideal for large-scale manufacturing, this machine combines safety, reliability, and high output in a user-friendly design.

The JLK500/6+12 Rigid Framed Stranding Machine is a high-performance solution for manufacturing bare copper, aluminum, and ACSR conductors. Designed for maximum efficiency, this machine produces round, sector, and tile-shaped cables with precision. Featuring automatic tension control, ground axis linkage, and pneumatic clamping, it ensures stable operation and consistent quality. The rigid frame structure enables high-speed rotation while maintaining accuracy, making it ideal for industrial cable production.

The 500/48+48 Steel Wire Armor Rigid Framed Stranding Machine is a robust, high-speed solution for stranding copper, aluminum, and ACSR conductors, including irregular conductor shapes. With integrated tape wrapping, pneumatic systems, and advanced control features, this machine ensures high efficiency, consistent tension, and superior conductor forming. It is ideal for large cross-section wire and cable production, offering enhanced safety, reliability, and productivity for demanding industrial applications.
